GEARBOX INPUT HOUSING BEARING

21 SPLINE MKII

This valve is assembled directly onto the lift cover Working ports: 3/8'' BSP 1 x Double acting spool section Handle 1 : Ports are plugged, spool has detent control. This handle is used to change between external and internal hydraulics Handle 2 : Working ports are 3/8'' BSP. Double acting spool with spring centre control. This handle is to control the external hydraulic function (implement/attachment of tractor). Oil returns from valve directly into the hydraulic lift head For 1 x double acting application only 2 pipes and fittings are required Ideal for operating log splitters, tipping trailers etc. Tractor models are for cabless platform tractors where the hydraulic lift cover is accessible.

This valve is assembled directly onto the lift cover Working ports: 3/8'' BSP 2 x Double acting spool sections Handle 1 : Working ports are 3/8'' BSP. Double acting spool with spring centre control. This handle is to control the external hydraulic function (implement/attachment of tractor). Handle 2 : Ports are plugged, spool has detent control. This handle is used to change between external and internal hydraulics. Handle 3 : Working ports are 3/8'' BSP. Double acting spool with spring centre control. This handle is to control the external hydraulic function (implement/attachment of tractor). Oil returns from valve directly into the hydraulic lift head For 2 x double acting applications only 4 pipes and fittings are required Ideal for operating log splitters, tipping trailers etc. Tractor models are for cabless platform tractors where the hydraulic lift cover is accessible.

DIFFERENTIAL LOCK CAP

Length: 120.7mm Width: 42.4mm Hole Diameter: 26.5mm

TRANSMISSION CIRCLIP x10

BRAKE ROD SPACER

COUNTERSHAFT CIRCLIP

REAR AXLE HALF SHAFT

PTO GEAR - 53 TEETH 15 SPLINE

PTO SHAFT BEARING
